| Parameter Item | Value |
| Unloading height (mm) | 3450 |
| Bucket width (mm) | 3050 |
| Engine model | Weichai 6 cylinder |
| Engine power (kW) | 178 |
| Rated speed (r/min) | 2200 |
| Horsepower | 242 |
| Drive axle model | 6 Ton Lunbian bridge |
| Tire specification | 23.5-25 |
| Gearbox model | ZL60 gearbox |
| Maximum speed (km/h) | 42 |
| Outside turning radius of bucket (mm) | 7290 |
| Overall weight (kg) | 18000 |
| Rated load mass (kg) | 6000 |
| Maximum traction (kN) | 170 |
| Maximum rising force (kN) | 175 |
| Unloading distance (mm) | 1220 |
| Wheel pitch (mm) | 2180 |
| Wheelbase (mm) | 3380 |
| Overall dimension (mm) | 899029803420 |
