| Parameter Item | Value |
| Unloading height (mm) | 3500 |
| Bucket width (mm) | 2450 |
| Engine model | Weichai 6 cylinder |
| Engine power (kW) | 92 |
| Rated speed (r/min) | 2000 |
| Horsepower | 125 |
| Drive axle model | 3 Ton Lunbian bridge |
| Tire specification | 17.5-25 |
| Gearbox model | 428 gearbox |
| Maximum speed (km/h) | 39 |
| Outside turning radius of bucket (mm) | 6110 |
| Overall weight (kg) | 9850 |
| Rated load mass (kg) | 3000 |
| Maximum traction (kN) | 101 |
| Maximum rising force (kN) | 98 |
| Unloading distance (mm) | 1010 |
| Wheel pitch (mm) | 1850 |
| Wheelbase (mm) | 2880 |
| Overall dimension (mm) | 756025203200 |
