3ton internal combustion forklift

3 Ton Diesel Forklift
Product advantages: Classic black appearance, stable diesel power, sturdy lifting mast, suitable for long-hour continuous operation.
Application scenarios: General factory workshop, warehouse stacking, logistics distribution center, outdoor freight yard.
Services we offer: Customization (tonnage, forks, lifting height, attachments, color, brand, EPA engine), 1-year after-sales service, free replacement of spare parts, certificates including ISO, CE, 724h online customer service and technical support. Tires can also be customized.

Get Inquiry

Product details

Model	–	CPC30
Power	–	Diesel
Rated lifting load	KG	3000
Load center distance	mm	500
Driving mode	–	Seat driving
Length with fork	mm	3930
Length without fork	mm	2690
Width	mm	1210
Height when the mast not raised	mm	2130
Overhead guard height	mm	2100
Wheelbase	mm	1700
Front overhang	mm	479
Rear overhang	mm	520
Minimum ground clearance	mm	110
No-load maximum lifting height	mm	3000
Free lifting height	mm	160
Minimum turning radius (outer side)	mm	2240
Mast tilt angle (front/rear)	(°)	6°/12°
No-load maximum lifting speed	mm/s	505
Full-load maximum lifting speed	mm/s	485
No-load maximum working speed	Km/h	20
Full-load maximum working speed	Km/h	18
Full-load maximum gradeability	%	20
Forklift weight under standard no-load condition	Kg	4200
Tire no. (F/R)	–	2/2
Tire type (F/R)	–	Air inflation tire
Tire size (F)	–	28×9-15
Tire size (R)	–	6.50-10
Brake/service brake	–	Power brake–pedal
Parking brake	–	Mechenical–manual
Battery voltage/capacity	V/Ah	12/80
Engine model	–	xinchai/quanchai490
Engine fuel tank capacity	L	60
